5L UN Approved Stackable Canister

HDPE Canister Supply

Product Specifications - 5L UN Approved Canister
Raw materials used are REACH compliant and UN approved for food contact.

Container
Weight: 250g ± 10%
Min. wall thickness: 0.55mm
Brimful volume: 5.3 litres
Neck: External thread with T/E ratchet
Material: HDPE (100% recyclable)
Closures: Din/51 T/E & Din/51 Vented
Closure box qty: 800 Per Box
Closing torque: 10Nm

Decoration
Label area: 2 Panels: H137 x W131mm
Colours: Natural (other colours on request)

Palletisation
Pallet dimensions: L1200 x W1000 x H2620mm
Pallet quantity: 400 Jerrycans per pallet
Pack qty: 2 packs of 200 Jerrycans
Units per layer: 40 Jerrycans
FVL: 10,400 Jerrycans (26 pallets)

Hight - 245mm (± 10mm)
Wide - 198mm (± 10mm)
Deep - 148mm(± 10mm)

Compatibility
Some chemicals, and process parameters, can affect the integrity of the container. The buyer must undertake testing and approval for the container's suitability for the product and application. UN certification is only valid with IPL approved closures.

Please send enquires to sales@dnapackaging.co.uk

10L UN Approved Stackable Canister

HDPE Canister Supply

Product Specifications - 10L UN approved Canister
Raw materials used are REACH compliant and UN approved for food contact.

Container
Weight:425 ±20 grams
Min. wall thickness: 1.1mm
Brimful volume: 11.25 Litres ± 250ml
Neck: External thread with T/E ratchet
Material: HDPE (100% recyclable)
Closure: DIN 61mm T/E
Closing torque: 16-18Nm

Decoration
Label area: 2Panels: H180.9 x W165.4mm
Colours: Natural (other colours on request)

Palletisation
Pallet dimensions: L1200 x W1000 x H2622mm
Pallet quantity: 208per pallet (2 packs of 104)
Units per layer: 26 per layer
Units per load: 5,408 (26 pallets)

High - 234mm (+5mm)
Wide - 234mm (+5mm)
Deep - 190mm (+5mm)

Compatibility
Some chemicals, and process parameters, can affect the integrity of the container. The buyer must undertake testing and approval for the container's suitability for the product and application. UN certification is only valid with IPL approved closures.

Please send enquires to sales@dnapackaging.co.uk

20L UN Approved Stackable Canister

HDPE Canister Supply

Product Specifications
Raw materials used are REACH compliant and UN approved for food contact.

Container
Weight: 800 ± 25 grams (without closure)
Min. wall thickness: 0.70mm
Brimful volume: 21.6 Litres ± 250ml
Neck: Bore = 44mm, Thread OCD = 60mm
Material: HDPE (100% recyclable)
Closure: DIN60 TE, DIN60 Vented
Closing torque: 16-20Nm

Decoration
Label area: 2 Panels: H220 x W214mm
Colours: Natural (other colours on request) Visi-stripe: Available

Palletisation
Pallet dimensions: L1200 x W1000 x H1491mm
Pallet quantity: 120 per pallet (2 packs of 60)
Units per layer: 20 per layer
Units per load: 2,640
Hight - 372.1mm (± 7mm)
Wide - 295mm (± 5mm)
Deep - 240mm(± 5mm)

Compatibility
Some chemicals, and process parameters, can affect the integrity of the container. The buyer must undertake testing and approval for the container's suitability for the product and application.

Please send enquires to sales@dnapackaging.co.uk

25L UN Approved Stackable Canister

HDPE Canister Supply

Product Specifications
Raw materials used are REACH compliant and UN approved for food contact.

Container
Weight: 900 ± 25 grams (without closure)
Min. wall thickness: 0.70mm
Brimful volume: 27.2 Litres ± 250ml
Neck: Bore = 44mm, Thread OCD = 60mm
Material: HDPE (100% recyclable)
Closure: DIN60 TE, DIN60 Vented
Closing torque: 16-20Nm

Decoration
Label area: 2 Panels: H298 x W214mm
Colours: Natural (other colours on request) Visi-stripe: Available

Palletisation
Pallet dimensions: L1200 x W1000 x H1491mm
Pallet quantity: 100 per pallet (1 pack of 60, 1 pack of 40)
Units per layer: 20 per layer
Units per load: 2,200 closures loosely loaded at rear of trailer if required
High - 446.7mm (± 7mm)
Wide - 295mm (± 5mm)
Deep - 240mm (± 5mm)

Compatibility
Some chemicals, and process parameters, can affect the integrity the container. The buyer must undertake testing and approval for the container's suitability for the product and application.

Please send enquires to sales@dnapackaging.co.uk
